Gold Mining Mill Equipment
Factory-direct ball mills, wet pan mills and grinding steel balls for gold ore plants — compare models and key specifications below, then send one inquiry for a matched quote.
Grinding & Processing Equipment
Ball mills and wet pan mills for small-scale gravity plants and continuous hard-rock circuits, sized to your ore, feed and throughput.
Grinding Equipment Gold Ball Mill
The continuous fine-grinding stage for hard-rock gold plants. Wet or dry operation with overflow or grate discharge, grinding crushed ore to the liberation size your gravity, flotation or leaching circuit needs.
- Models: Φ900×1800–Φ1830×4500
- Capacity: 0.65–12 t/h
- Feed size: ≤ 20–25 mm
- Power: 18.5–155 kW
Grinding Equipment Wet Pan Mill for Gold
A compact, economical double-wheel grinding machine for small and medium gold plants. Crushed ore and water are ground into recovery-ready slurry in one step — lower investment, simple foundations, easy on-site repair.
- Models: 900–1600
- Capacity: 0.3–10 t/h
- Feed size: ≤ 15–30 mm
- Power: 5.5–30 kW
Mill Consumables & Media
Application-matched grinding media and process consumables, batch-inspected and packed for reliable export supply.
Grinding Media Forged Grinding Steel Balls
Forged and hot-rolled grinding media for gold and copper ball mills, in diameters from 20 to 150 mm as a graded charge. Hardness and toughness are matched to your mill duty, ore abrasiveness and top-up schedule.
- Diameter: 20–150 mm
- Hardness: HRC 55–65
- Process: Forged / hot-rolled
- QC: Per-batch checks
Request a Quote
Share your requirements and receive a clear quotation for your project.
- Direct factory supply
- Technical configuration support
- Export packing and documents
- Parts and after-sales support
